Specification

Pump Body Material: Engineering Plastic

Color: Blue

Valve Material: EPDM

Diaphragm Material: TPE

Pump Head Material: PA

Valve Seat Material: POM Plastic

Voltage: 110V

Current: 2.5A

Power Frequency: 50HZ

Rated Power: 275W

Connection Method: Thread

Voltage Fluctuation Range: +-10% of rated value

Volume of Solid Impurities In the Medium: <=0.1

Media Containing Solid Impurities In the Particles: <0.2mm/0.004in

Stop Pressure: 55PSI/3.8BAR

Control Mode: Pressure/Return Switch

Wiring Method: Double-core Wire

Ambient Temperature: Less than or Equal to 50℃

Medium Temperature: 0-65℃

Medium PH: 5.0-10

Rated Flow Rate: 18.9L/min

Rated Head: 38m/124.67ft

Inlet Size: 1/2in-14 Male Threaded Interface

Pressure Adjustment Range: 1-4.1kg/2.20-9.03lbs

Product Size: 23.3*12.6*10.9cm/9.2*5*4.3in

Package Size: 29.9*14.6*12.8cm/11.77*5.74*5.03in

Net Weight: 2.80kg/6.17 lbs

Gross Weight: 2.84kg/6.26lbs
